• A 166.5 kWp PV Solar System for the Technological University of the Shannon (TUS).

• 370 x 450W PV modules have been installed on seven roof sections with a total area of 8,000 sq ft at the TUS Moylish Campus in Limerick.

• 3 south-facing sections

• 4 east-west facing sections

• Total estimated kilowatt delivered yearly 136, 615 kWh

• Equivalent yearly kilowatt supply of approximately 30 average households.

• 64 tons of CO2 emissions avoided every year

• 160kW rooftop solar system
• On-site EV charging stations
• LED lighting upgrade
• The company’s Gort-based facility is already manufacturing their bespoke modular units for the construction sector, using up to 99% solar power from a newly constructed rooftop solar system.
• 301 PV modules on 2 slopes of the roof divided in 12 module fields on each slope
• Panel model: Jinko Solar’s Tiger Pro 530W model, which is perfect for self-consumption and industrial solar installations. EnergieXPro® was the first company to use these high-performance PV Modules in Ireland. The panels have higher output and efficiency (over 20%) which is extremely important and beneficial in the West of Ireland.
• 2 x two top–of-the range GoodWe 80kW MT Series inverters with 24 string input capabilities and a maximum efficiency of 98.4%.
• Battery storage: a battery storage system to support the installation and to help achieve close to 100% use of self-generated power. The battery manufacturer Sofar Solar had just launched a new battery storage product line and thanks to their close relationship with Sofar, EnergieXPro® were able to supply and install the world’s first 20 kW AC coupled battery units. А total of 3 x 25kW Amass Towers were supplied, making it the first install of its kind in Europe, and meeting the challenges of the restricted space available.

• A Turnkey 73,488 kWp Rooftop Solar PV and battery storage system, covering Bellissimo’s energy needs by 60 to 80%.
• 207 x 355W high performance QCELLS Q.PEAK DUO-G8 panels, generating a total of 75 kW of power.
• Two top-of-the range GoodWe 36kW inverters with 24 string input capabilities and a maximum efficiency of 98.4%.
• 1 x SKW hybrid GoodWe inverter powering high voltage battery, all controlled by a GoodWe SEC1000 controller
• Battery storage: 1 x Soluna 15K Pack is a three-phase battery module that enables energy storage to maximise self-consumption from your solar system to reduce electricity bills and provide energy independence.
• LED lighting and heat pumps were also installed to further reduce Bellissimo’s energy usage.

Stats

• 73,488 kWp installed
• 414 m of roof covered
• 52 MW delivered yearly
• 03 Tons CO2 Reduction
• 3027 Planted trees
• 37 Tons Coal savings

• System size: 60.03 kW

• PV Module: Q.PEAK DUO-G8+ 345-360 by QCELLS

• Number of panels: 174

• 2 x Fronius Eco 27kW Inverter

• Battery storage: 3 x Dyness Tower T17, each 17.76 kWh

• 3 X 10kW GoodWe AC coupled units

• G10 safety relay

• GoodWe SEC1000 Controller

• 48,800 kWh Energy generation

• 23 MT of carbon reduction

• Installed Capacity:  52 kWp

• PV Panel: Jinko Solar, MM450-60HLD-MBV, 450W

• Number of PV Panels: 158

• Orientation: South

• Inverters: 1 x Goodwe, GW50KN-MT

• 50kW Three Phase with DC Switch & Wifi

• Smart Energy Controller: Goodwe SEC 1000

• Annual Energy Production: 49,459 kWh

• Annual CO2 Reduction: 24.2 MT

• Installed Capacity: 19.6 kWp

• Inverters: GOODWE,  1 x 12 kW String & 1 x 8 kw Hybrid

• PV Panel: Q.PEAK DUO-G8+, 350W

• Battery Storage: Soluna 15kWh  High Voltage

• Number Of PV Panels: 56

• Annual Energy Production: 16,660kWh

• Orientation: East/West

• Annual CO2 Reduction: 9.21 MT

• Infra Red Heater: 5 x 2,400W & Infra Red Towel Rails

• 1 x Salus Control unit

• LED Lighting

• System size: 41.41 kWp photovoltaic roof-mounted system
• PV Module: 455-watt Sunport PV Modules
• Number of panels: 91
• 1 x 36 kW GoodWe inverter
• 3 Fire switches – Aswich
• G10 Safety relay
• Mounting system: Renusol
• 38,092.60 kWh energy generation per year
• Smart Energy Controller
• CO₂ Emissions avoided: 19,143 kg/ year

• System size: 91 kWp photovoltaic roof-mounted system
• PV Module: 455W Jinko Solar PV modules
• Number of panels: 400
• 1 x 40 kW Sofar string inverter, 1x 20 kW Sofar hybrid inverter
• Battery: 100 kWh hours of Amass LFP battery storage
• G10 fuse relay for ESB compliance
• CO2 Emissions avoided 39,653 kg / year

• Installed Capacity: 6.2 KWp (6,210 Wp)

• Inverters: SoFar HYD 6000-ES Hybrid Inverter

• PV Panel: Hanwha Q Cell 345

•  Battery Storage: Dynas 9.6 kW

• Number Of PV Panels: 18

• Annual Energy Production: 5,589 kWh

• Orientation: South

• Annual CO2 Reduction: 2.9 tonnes

• Installed Capacity: 7.1 kWp

• Inverters: 2 x 5kW and 1.5kW Goodwe Hybrid

• PV Panel: QCELLS, Q.PEAK Duo – G8+ 355W

• Battery Storage: 2 x Dyness 4.8kWh

• Number Of PV Panels: 20

• Annual Energy Production: 6,035 kWh

• Annual CO2 Reduction: 3.34 MT

• Copper Cylinder: 300 Litre with 90 Litre Buffer

• Heat Pump: Mitsubishi Ecodan, 14kW split outdoor unit

• Installed Capacity: 7.1 kWp

• Inverters: 5 kW & 2kW Goodwe

• PV Panel: QCELLS, Q.PEAK Duo – G8+ 355W

• Battery Storage: Dyness 4.8 kWh

• Number Of PV Panels: 20

• Annual Energy Production: 6,035 kWh

• Annual CO2 Reduction: 3.34 MT

• Copper Cylinder: Dejong 300 Litre

• Heat Pump: Mitsubishi Ecodan, 14kW split outdoor unit

• Installed Capacity: 10.351kWp (10.350 kWh)
• Inverters: 2x 5kw Sofar 5.0 KTLM G2
• PV Panel: QCELLS, Q.PEAK Duo – G8+ 345W
• Battery Storage:  2 x Dyness 9.6kW
• Number Of PV Panels: 30
• Annual Energy Production: 8,797 kWh
• Orientation: South
• Annual CO2 Reduction: 4.86 MT
• AC Coupled Unit: Goodwe AC Coupled Unit 10kw
• Water Cylinder: 300 Litre with 90 Litre Buffer
• Heat Pump: Mitsubishi Ecodan

• Installed Capacity:  9.72 kWp

• Inverters: 1 x Goodwe, 5kW

• PV Panel: JA Solar JAM72S10-405/MR, 405W

• Battery Storage: Dyness Power Deport 4.8kWh

• Number Of PV Panels: 24

• Annual Energy Production: 7,295 kWh

• Installed Capacity: 10.9 kWp (9.299 kWh)
• Inverters: 1 x 8kw Sofar HYD 8KTL-3PH & 1 x 3kw Saj Sununo Plus 3K-M
• PV Panel: Jinko, JKM405N-54HL4-B (405W)
• Number Of PV Panels: 27
• Battery Storage: 10 kW (4 x 2.5 kW Amasstore GTX3000-H)
• Annual Energy Production: 9.299 kWh
• Orientation: South & Southeast

• Installed Capacity: 6.08 kWp
• Mounting System: Renusol Freestanding ballasted PV mounting system
• Inverters: 1 x 5 kW Goodwe inverter
• PV Panel: Jinko, Tiger Pro 54HC 395-415 Watt
• Number Of PV Panels: 15
• Battery Storage: 2 x 5.10 kWh Dyness Energy Storage System (ESS)
• Annual Energy Production: 5,285.25 kWh
